Description
ECLER SAM412T is an installation mixer in standard rack format. It includes 4 MIC / ST LINE inputs, 2 stereo outputs, independent 3 band tone control per each input, Talkover (priority) function and external MUTE connection port.
SAM412T
4×2 | 1U rack | 3-band EQ | analogue mixer
Installation Preamps And Mixers | Reference: CSAM412T
- 4 input channels, 2 main outputs 19” installation mixer
- Micro sensitivity level can be adjusted on the back panel
- +18V Phantom Power available in all “MIC” inputs
- Direct micro input on front panel, channel 1
- Includes a talkover assigned to “INPUT 1” with internal release time adjustment
- Three-band tone controls for each channel, accessible with a screwdriver
- Vu-meter for the mix signal
- Two internally adjustable output levels
- Recording output
- Direct access to the mixing bus allowing you to connect another mixer and increase the number of inputs
- Remote MUTE control affecting all inputs for connecting fire detection systems other safety devices. Internally programmable “NO / NC” (normally open, normally closed)
- Mono/stereo switch
